Product Details
The Sinotruk HOWO 6×4 371HP Dump Truck is a high-performance, cost-effective heavy-duty tipper truck engineered for harsh construction, mining, earthmoving, and material transportation scenarios. Powered by a reliable WD615.47 6-cylinder turbocharged diesel engine with a maximum output of 371HP and peak torque of 1590N·m, this truck delivers powerful low-speed traction and outstanding climbing performance, easily handling full loads of 25 to 40 tons on mountainous, muddy and rocky rough roads. Matched with a HW19710 10-speed manual transmission, it ensures smooth power transmission, stable operation and improved working efficiency, while the optimized fuel injection system effectively reduces overall fuel consumption and daily operating costs. Complying with Euro II emission standards, the powertrain features a simple and durable structure, bringing low failure rates and convenient maintenance for Africa remote working sites.
Built with a heavy-duty 6×4 ten-wheel chassis, the truck adopts a 9-ton front axle and 16-ton reinforced wheel-side reduction rear axles, paired with a thickened high-tensile steel double-layer frame that offers exceptional load-bearing capacity, impact resistance and structural stability. The optimized body track and excellent approach and departure angles guarantee superior trafficability on complex terrains. Equipped with a premium HYVA hydraulic lifting system, the high-strength wear-resistant steel cargo box with customizable volumes of 18–22m³ realizes fast, smooth and safe tipping and unloading, greatly shortening working cycle time and improving transportation efficiency for ore, gravel, soil and construction waste transportation.
Analysis Diagram
| Model | Sinotruk HOWO 371 6×4 Dump Truck |
| Driving Type | 6×4 (10 wheels) |
| Engine Model | WD615.69 (Euro II / Euro III) |
| Engine Power | 371 HP (273 kW) @ 2200 rpm |
| Displacement | 9.726 L |
| Maximum Torque | 1500 N·m @ 1100–1600 rpm |
| Transmission | HW19710 (10 forward + 2 reverse) manual |
| Clutch | Φ430 mm diaphragm spring |
| Suspension | Heavy Duty Suspension |
| Tire Size | 12.00R20 (11+1 pieces, including spare) |
| Fuel Tank | 300 L (optional 400 L) |
| Overall Dimensions (L×W×H) | Approx. 8.45 × 2.5 × 3.45 m |
| Cargo Box Volume | 18 – 25 m³ (optional: 18, 20, 22, 25 m³) |
| Cargo Box Liner Thickness | Bottom 10 mm, side 8 mm |
| Max Payload | 31 – 40 tons (depending on configuration) |
| Gross Vehicle Weight (GVW) | 31,000 kg (31 tons) |
| Steering | Power steering, left-hand drive (LHD) / right-hand drive (RHD) optional |
| Tipping Type | Rear tipper (hydraulic telescopic cylinder) |
